1.Totally EU streamlined design,Monoblock by welding robots & aparatus and stress relief process by Annealing treatment.
2.All Faraday machines are designed using SOLID WORKS 3D programming and made with enhanced ST44-1 quality steel with the latest technology.
3.MB8 Series are among the highest rated machines which will help you increase your productivity and keep costs at minimum levelwith its user friendly CNC controller and low cost hydraulic maintenance.
4.High quality and repetitive bending is obtained by using synchronized cylinders and valves.
5.Automatic axis referencing and calibrating when machine is turned on.
6.Rigid upper beam runs on 8-point bearings with bending precision of 0.01 mm
7.Wellknown top and bottom tool brands are long lasting stiffened and provide precise bending. Silent high pressure pump.
Delem DA52s CNC Press Brake Control system:
1.6,4” VGA colour LCD (TFT)
2.Numerical, one page programming
3.Quick, one-page programming
4.Up to 4 axes (Y1, Y2, and 2 auxiliary axes)
5.CNC Crowning control
6.USB, peripheral interfacing
8.Servo, frequency inverter and AC control for backgauge axes.
The best bending resultsYou can bend longer and deeper parts with standard SC/MB8-Bend Series.
2.Full synchronisation of Y1 + Y2 axes with proportional hydraulic valve system and constant monitoring by CNC system to +/- 0.01mm accuracy
3.High precision linear scales for measurement of stroke depth mounted on side frames rather than top beam to prevent any distortion in accuracy as beam comes under load
4.CNC-controlled X & R-axis as standard ballscrew backgauge with servo drive motors.
6.Two micrometric backgauge finger-stops with lateral adjustment
7.Steel mono-block construction
8.Polished chrome plated and ground cylinders
9.Long stroke and large open height dimensions
10.High approach and return speeds for production bending.
11.Euro style quick release top tool holders with intermediaries including wedges for crowning
12.88 degree sectionalised goose neck top tool
13.4 way sectionalised multi vee bottom tool
14.Double footswitch control and pendant type control arm.
15.AKAS laser tooling guards
16.Electrically interlocked side guards ;
17.Electrically interlocked read access door
18.2 sliding front support arms with linear guide rails for lateral adjustment and hand wheel for height adjustment, 1000mm long from centre of bottom tool vee.
19.Side guard is standard meeting CE regulations.
Packaging & Shipping
Anny ZhengSales Manager
Mob/whatsapp: 0086- 19965382660
Anhui aoxuan heavy industry machine Co., Ltd
Address: Wst Ind.Zone,Bowang New Zone,Ma'anshan,Anhui ,China (Mainland)
Q:How about your machine quality?
A:Our machines distribute worldwide to about 50 countries where there are metal plate industry ,there are Brilliante machines.And where there are our machines,there are good reputation and terminal user satisfaction.
Q:The machine price can be more discount?
A: We think about our price level,we are sure to provide quality=price and price=quality ,the matched price and acceptable for the clients and durable for our machines.We welcome your negotiate with us and get a good satisfaction. and Increase the order quality or long-term cooperation in the future will get our discount.
Q: Where is your factory?
A:We located in Ma'anShan City, Our factory is particularly close to Nanjing, about an hour, if you are to visit the factory .We can pick you up at the airport.Welcome to visit our factory!
